Bugle Head Heavy-Duty Wood Screws
Head Type：Bugle Head
Thread Type：Coarse Thread
Material Options：Carbon steel /Stainless steel（304/316）
Finish / Coating：Class 3/Ruspert / Yellyow Zinc
Applications：
- Structural timber-to-timber connections
- Fixing beams, posts, and heavy timber members
- Pergolas, decking structures, and outdoor timber construction
- Applications requiring high load capacity and flush finish
Designed for heavy timber construction, this bugle head Type 17 screw delivers strong load transfer, reduced timber splitting, and reliable long-term performance in structural applications.
| Size | Length (inch) | Length (mm) | Dia (mm) | Drill Tail |
|---|---|---|---|---|
| BUGLE BATTEN 14–10 × 50 | 2″ | 50 | 6.3 | Type 17 |
| BUGLE BATTEN 14–10 × 65 | 9/16″ | 65 | 6.3 | Type 17 |
| BUGLE BATTEN 14–10 × 75 | 3″ | 75 | 6.3 | Type 17 |
| BUGLE BATTEN 14–10 × 100 | 4″ | 100 | 6.3 | Type 17 |
| BUGLE BATTEN 14–10 × 125 | 5″ | 125 | 6.3 | Type 17 |
| BUGLE BATTEN 14–10 × 150 | 5-7/8″ | 150 | 6.3 | Type 17 |
| BUGLE BATTEN 14–10 × 200 | 7-7/8″ | 200 | 6.3 | Type 17 |
